YS-1850
SINGLE BAND
ITEM |
SPECIFICATION |
| PART/UNMBER | ST-070202 |
|
MODEL | YS-1850 |
|
ANTENNA TYPE | DIPOLE ANTENNA |
|
ANTENNA FORM | 0¢X-90¢XSWIVEL TYPE |
| FREQUENCY RANGE | 1850-1990MHZ |
|
BANDWIDTH | 140MHZ |
|
GAIN | ≤2.0dBi |
| V.S.W.R | 2.0:1 Max |
|
IMPEDANCE | 50£[ |
|
POLARIZATION | VERTICAL |
| LENGTH |
205¡Ó3 |
| OPERATLNGTEMPERATURE |
-30¢J ~+60¢J |
|
PULLING STRENGTH | 3kgf Min |
|
SWIVEL TORQUE | 3kgf Min |
|
CONNECTOR TYPE | TNC-MALE |
|
|
