| Antenna(25×25×4mm) | |
|
Frequency |
1575.42MHz±3MHz |
| V.S.W.R |
1.5Max |
| Band Width | ±5MHz |
| Attenuation |
fo±100MHz>30dB |
|
Impendence |
50Ω |
| Peak Gain | >3bBic(Based on 7”×7” Ground Plane) |
| Gain Coverage | >-4dBic(at -90º-90º,over 75% Volume) |
| Polarization |
RHCP |
| LAN Amplifier | |
|
LNA Gain (Without cable) |
24dB/27 dB Typical/30dB |
| Noise Figure | 1.5dB |
| V.S.W.R |
< 2.0 |
| DC Voltage | 5.0V |
| DC current | 20MA Max. |
| Mechanical |
|
| Weight |
<106 grams |
| Size |
48×40×14mm |
| Cable |
RG-174 |
| Connector |
SMA |
| Mounting |
Magnetic base |
| Housing |
Black |
